HLAD-3G
> Products > Commercial > HLAD-3G
Unique Features
Compact SizeLaser(Green), IR Laser, IlluminatorCrane Type PlugSpecifications
· Mechanical Specification
| WEIGHT(WITH BATTERY) | < 8.8oz / < 250grams |
| OVERALL DIMENSIONS (LxWxH) |
104 x 58 x 42mm |
· Laser Specification
| POWEROUTPUT | Visible Green Pointer : <5mW (HIGH)
IR Pointer : <0.7W (HIGH) Illuminator Pointer : <5mW (HIGH) |
| WAVELENGTH |
Visible Green Pointer : 520 ~ 540nm IR Pointer : 835 ~ 860nm Illuminator Pointer : 835 ~ 860nm |
| BEAMDIVERGENCE |
Visible Green Pointer : <0.3 mrad IR Pointer : <0.3 mrad Illuminator Pointer : 1 ~ >100 mrad |
| LASERTYPE | Visible Green Pointer : Class 3R
IR Pointer : Class 1 Illuminator Pointer : Class 3R |
| BATTERY |
CR123A(Lithium, 3V)@1 |
| BATTERYLIFE |
DH(Dual Mode High) : 10h |
